FB-IX ( 4 Wheel, 1.0-3.5 ton)

ELECTRIC COUNTER-BALANCE FORKLIFT TRUCK
FB-IX

  • Counterbalanced electric four wheel forklifts (Pneumatic tire model)
  • Load capacity range : Fron 1.5 to 3.5 ton (Load center : 500mm)
    • Power source : Electric-power
    • IPX4 - Preventing water entry
    • Strong frame for superior endurance
    • ECO (Energy saving) mode
    • Regenerative brake
    • Auto power off
    • Operation mode selection & customized mode
    • Smooth running system (Option)
    • Easy battery exchange system (Option)
    • The main truck specifications are shown as follows:

Main Truck Specifications

ModelLoad CapacityLoad CenterLength (Without Forks)WidthOverhead Guard HeightTurning Radius
FB10-91000kg500mm2080mm1110mm2110mm1850mm
FB15-91500kg500mm2080mm1110mm2110mm1850mm
FB18-91750kg500mm2120mm1115mm2110mm1880mm
FB20-92000kg500mm2305mm1155mm2110mm2030mm
FB25-92500kg500mm2345mm1155mm2110mm2080mm
FB20-9LB (Long Wheelbase)2000kg500mm2465mm1155mm2110mm2215mm
FB25-9LB (Long Wheelbase)2500kg500mm2465mm1155mm2110mm2215mm
FB30-93000kg500mm2505mm1255mm2200mm2260mm
FB35-9S3500kg500mm2600mm1255mm2200mm2330mm
