STW12T-B/14T-B/18T-B Straddle Stacker｜Products

STW12T-B
STW14T-B
STW18T-B

The innovative AC system offers strong power, accurate control, excellent performance
High strength vertical gearbox, longer working life
Low noise but durable hydraulic unit, good quality cylinder as well as hose ensure the high reliability of hydraulic system
H shape channel mast improves the strength of the whole truck
Straddle design ensures the stability of high lifting
Safe hydraulic system design prevents mast from falling down abruptly when hydraulic pipeline cuts off
Emergency reverse belly button protects the operator from getting hurt
Long operational tiller ensures safety distance for operators
Adjustable forks, suitable for complicated pallets or cargos
AC traction motor, maintenance free

Main Truck Specifications

	Operator Type	Load Capacity	Load Center	Lift Height	Height-Mast Lowered	Overall Length	Overall Width	Turning Radius	Travel Speed-Laden	Travel Speed-Unladen
STW12T-B	Pedestrian	1200kg	600mm	3270mm	2100mm	1947mm	1120/1420mm	1490mm	5.0km/h	5.5km/h
STW14T-B	Pedestrian	1400kg	600mm	3200mm	2118mm	1987mm	1270/1370/1470mm	1545mm	5.0km/h	5.5km/h
STW18T-B	Pedestrian	1800kg	600mm	3200mm	2118mm	2092mm	1270/1370/1470mm	1645mm	4.5km/h	5.0km/h
