Products Line Up

Reach Trucks (Narrow aisle, four way, swivel operations)

Reach
Trucks

<Product Features>

  • Sit-on reach trucks (Electric-powered) for narrow aisle operations.
  • Power source : Electric motors
  • Diverse ranges of reach trucks including swivel trucks and four way trucks are available as follows:

Main Truck Specifications

ModelTypeLoad capacityLoad capacityTruck width
RTL 120Narrow chassis reach truck1200kg600mm1120mm
RTL 140Narrow chassis reach truck1400kg600mm1120mm
RTNNarrow chassis reach truck (Drive-in rack type)1400kg600mm1120mm
RTM 160Reach truck1600kg 600mm1270mm
RTM 200Reach truck2000kg600mm1270mm / 1397mm
RTH 200Reach truck2000kg600mm1270mm / 1397mm
RTH 250Reach truck2500kg600mm1397mm
RTXReach truck (High mast type)2000kg600mm1397mm
RTFFour way reach truck2000kg / 2500kg600mm1498mm / 1744mm
RTSSwivel reach truck1250kg / 1500kg600mm1450mm
