Products Line Up

Order Pickers

For high level &
low level
order picking

<Product Features>

  • High level & low level order pickers
  • Power source : Electric-powered motor
  • Order pickers in diverse range are available as follows for your picking operation in warehouse.

Main Truck Specifications

TypePicking levelLoad capacityTruck lengthTruck widthTurning radius
OPMHigh level picker4500mm1000kg2032mm950mm1931mm
OPHHigh level picker6900mm1000kg2032mm950mm1931mm
OPCHigh level picker7800mm1000kg2040mm1070mm2024mm
OPSHigh level picker9850mm1000kg2050mm1170mm2036mm
ModelTypeChassisLift heightLoad capacityTruck lengthTruck width
PPL 200/250 (JN)Low level picker - low lifterJunior chassis230mm2000kg / 2500kg1349mm + fork length790mm
PPL 200/250 (SN)Low level picker - low lifterSenior chassis230mm2000kg / 2500kg1430mm + fork length790mm
PPD 200/250 (JN)Low level picker - Driver platform upJunior chassis230mm2000kg / 2500kg1349mm + fork length790mm
PPD 200/250 (SN)Low level picker - Driver platform upSenior chassis230mm2000kg / 2500kg1430mm + fork length790mm
PPC 120 (JN)Low level picker - fork & driver platform upJunior chassis950mm1200kg1455mm + fork length790mm
PPC 120 (SN)Low level picker - fork & driver platform upSenior chassis950mm1200kg1536mm + fork length790mm
PPF 120 (JN)Low level picker - fork upJunior chassis950mm1200kg1455mm + fork length790mm
PPF 120 (SN)Low level picker - fork upSenior chassis950mm1200kg1536mm + fork length790mm
PPS 200Low level picker - scisor lift-900mm2000kg1536mm + fork length790mm
